IB Physics Energy Production Questions: Exam Guide

RevisionDojo Team

•7/30/2026•14 min read

IB Physics energy production questions become much easier when you treat them as energy-accounting problems rather than a collection of power-station facts. Identify the input energy, follow each transformation, distinguish useful output from wasted energy, and then apply conservation of energy, power, or efficiency.

These questions appear in several forms, including calculations, Sankey diagrams, data analysis, explanations of generating systems, and evaluations of energy sources. The contexts vary, but the underlying methods and common traps are remarkably consistent.

Is Energy Production Still an IB Physics Topic?

Under the syllabus last assessed in 2024, Energy Production was officially Topic 8. It included energy sources, Sankey diagrams, power stations, wind power, hydroelectric storage, thermal radiation, and the greenhouse effect.

The current IB Physics course, first assessed in 2025, is organized into five themes rather than numbered core topics. Energy-production ideas are now distributed across areas such as A.3 Work, energy and power, B.1 Thermal energy transfers, B.2 Greenhouse effect, D.4 Induction at HL, and E.4 Fission. The IB also replaced the former three-paper structure with Paper 1 and Paper 2, while removing the option topics.

This distinction matters when using older past papers. Legacy Energy Production questions remain valuable for practising energy transformations, efficiency, power, radiation, and data interpretation, but some technology-specific material may no longer be explicitly required. Check questions against your current syllabus before spending time memorizing details such as the construction of particular power stations.

According to the IB's current Physics assessment update:

Paper 1A contains multiple-choice questions.
Paper 1B assesses data analysis and experimental skills.
Paper 2 begins with short-response questions and ends with extended-response questions that can connect different parts of the course.

The official specimen papers and markschemes demonstrate these formats. Energy contexts can therefore appear as direct calculations, unfamiliar data sets, or part of a larger cross-topic problem.

The Recurring Energy Production Question Types

Question type	What you must recognize	Typical method
Energy transformation	Energy changes form but is conserved	Write an energy chain and identify losses
Efficiency	Only part of the input becomes useful output	Use useful output divided by total input
Power	Energy is transferred over time	Apply $P=E/t$
Sankey diagram	Arrow widths represent energy or power	Compare useful and wasted branches
Wind or hydro calculation	Kinetic or gravitational energy drives a generator	Find available power, then apply efficiency
Data analysis	A graph or table replaces a familiar formula	Read scales, calculate gradients, and describe evidence
Nuclear generation	Fission releases energy through mass loss	Explain the chain reaction and energy transformations
Evaluation	Sources have competing physical and environmental effects	Make specific comparisons supported by data

These categories overlap. A question may ask you to calculate an input power, complete a Sankey diagram, and then explain why the real output is lower than the theoretical value.

A Reliable Method for Calculation Questions

1. Establish the system boundary

Decide what equipment or process the stated efficiency covers. A turbine efficiency is not automatically the efficiency of the entire power station, and transmission losses should not be included unless the question places them inside the system.

Write a short energy chain before calculating. For a thermal power station, one simplified chain is:

chemical or nuclear energy → thermal energy → kinetic energy of steam → rotational kinetic energy → electrical energy

At each stage, some energy is transferred to the surroundings, principally through heating and sound.

2. Separate energy from power

Energy is measured in joules, while power is the rate of energy transfer and is measured in watts:

P=\frac{E}{t}

A frequent error is to substitute an energy value directly into an efficiency calculation involving powers without checking that the quantities are compatible. Efficiency may be calculated using energies or powers, but the numerator and denominator must be of the same type and refer to the same time interval.

3. Apply efficiency in the correct direction

\eta=\frac{E_{\text{useful}}}{E_{\text{input}}} =\frac{P_{\text{useful}}}{P_{\text{input}}}

Therefore:

E_{\text{useful}}=\eta E_{\text{input}}

but

E_{\text{input}}=\frac{E_{\text{useful}}}{\eta}

Convert a percentage to a decimal before substitution. An efficiency of 32% is $0.32$ , not 32.

4. Keep units visible

Convert megajoules to joules, kilowatts to watts, and minutes to seconds before calculating. A correct numerical method can still produce an answer wrong by a factor of $10^3$ or $60$ if unit conversions are delayed or omitted.

Worked example: output power

A generating system receives $750\text{ MJ}$ of energy in $25\text{ s}$ and has an efficiency of 32%. Calculate its useful output power.

E_{\text{useful}}=0.32(750\times10^6)=2.40\times10^8\text{ J}

P_{\text{useful}}=\frac{2.40\times10^8}{25} =9.6\times10^6\text{ W}

The useful output power is therefore 9.6 MW. The order matters: find useful energy from the efficiency, then divide by the stated time.

How to Handle Sankey Diagrams

A Sankey diagram represents energy or power flows using arrow widths. The main input arrow divides into useful output and one or more wasted outputs, so conservation requires:

E_{\text{input}}=E_{\text{useful}}+E_{\text{wasted}}

Suppose a power station receives $500\text{ MJ}$ and produces $175\text{ MJ}$ of electrical energy. Its efficiency is:

\eta=\frac{175}{500}=0.35=35\%

The wasted energy is $500-175=325\text{ MJ}$ . If completing a diagram, the useful and waste arrows should have widths in the ratio 175:325, while their combined width must match the input arrow.

Do not say that energy is “lost.” Energy is conserved, but some is dissipated to the surroundings and becomes less useful. That wording is physically accurate and usually closer to what a markscheme rewards.

Wind, Hydroelectric, and Variable-Output Questions

Older Energy Production questions often use the available power in moving air:

P_{\text{wind}}=\frac{1}{2}\rho Av^3

The cubic dependence is the central idea. Doubling wind speed increases the available wind power by a factor of $2^3=8$ , provided density and swept area remain constant. The electrical output is lower because a turbine cannot extract and convert all the incoming kinetic energy.

For hydroelectric generation, begin with gravitational potential energy:

E=mgh

If water flows at a mass rate (m/t), the available power is:

P=\frac{mgh}{t}

With volume flow rate $Q$ and water density $\rho$ , this can be written as $P=\rho Qgh$ . Apply turbine or generator efficiency only after calculating the available input power.

In data-based questions, avoid claiming that variable output makes a source useless. A stronger answer explains that output depends on environmental conditions, so storage, backup generation, demand management, or connection to a wider grid may be required.

Nuclear Energy Questions

Current nuclear questions are most likely to connect energy production to fission, binding energy, mass defect, and induced chain reactions. In a fission reactor, a neutron is absorbed by a heavy nucleus, which becomes unstable and splits into smaller nuclei while releasing energy and additional neutrons.

A complete reactor explanation should distinguish the functions of major components:

A moderator slows neutrons, increasing the probability of further fission in suitable reactor designs.
Control rods absorb neutrons and regulate the reaction rate.
A coolant transfers thermal energy away from the reactor core.
A heat exchanger or steam system ultimately transfers energy to a turbine and generator.

Do not state that control rods slow neutrons or that the moderator absorbs most neutrons. These are common role-reversal errors. When discussing risk, distinguish low-probability accidents from long-term radioactive waste, mining impacts, operational emissions, and reliability.

Answering Data and Evaluation Questions

Paper 1B can place energy concepts inside an unfamiliar table, graph, or experimental context. Begin by identifying the independent and dependent variables, reading axis scales carefully, and recording units with every extracted value.

When asked to describe a trend, report what the data show before explaining it. For example: “Output power increases rapidly with wind speed and approximately follows a cubic relationship” is stronger than simply writing “power increases.” If uncertainty bars overlap, avoid claiming that two measurements are definitely different.

Evaluation questions require balanced, specific physics. Compare sources using criteria such as:

available power and reliability
efficiency and energy losses
startup or response time
storage requirements
land and material use
operational emissions and waste
geographical constraints
safety and long-term environmental effects

Avoid absolute statements such as “renewable energy causes no pollution” or “nuclear energy is completely clean.” Examiners reward qualified claims that identify the stage of the energy system being considered.

Common Mistakes That Lose Marks

Treating energy and power as interchangeable quantities.
Multiplying by efficiency when the required quantity is the input.
Using a percentage as a whole number rather than a decimal.
Forgetting that wind power depends on $v^3$ , not $v$ .
Calling dissipated energy “destroyed” or “used up.”
Confusing the moderator, control rods, and coolant in a reactor.
Giving generic advantages without connecting them to the named energy source.
Memorizing legacy Topic 8 material without checking the current syllabus.
Rounding intermediate values too early.
Writing a numerical answer without a unit or reasonable significant figures.

The Fastest Way to Build the Method

Re-reading notes helps recover definitions, but it does not fully train question recognition. A more effective cycle is to attempt a question under timed conditions, commit to a complete solution, and then compare every step with a worked solution.

The RevisionDojo Energy Production Questionbank organizes relevant practice by topic. After each attempt, use the IB Physics video solutions to see how the information is extracted, which equation is selected, and how the final answer is presented. Watching a solution before attempting the question removes the most important part of the exercise, which is deciding what to do independently.

Keep an error log with three columns: error, reason, and correction. Use the A.3 power and efficiency notes when a conceptual gap appears, and practise locating equations in the IB Physics data booklet resource. Jojo AI can help explain why a particular method failed, but you should then solve a similar problem without assistance.

Conclusion

IB Physics energy production questions repeatedly test the same core habits: trace energy transformations, define useful output, distinguish energy from power, apply efficiency in the correct direction, and support explanations with precise physics. Older Topic 8 questions remain useful, provided you separate transferable skills from content no longer explicit in the current course.

The most productive revision is active. Attempt questions first, diagnose each error, and then watch the method being worked through. RevisionDojo's Energy Production Questionbank and per-question Physics video solutions are the most relevant tools for building that exam routine.
