Which waves formulas should I know for IB Physics?

You should be able to recognize and apply relationships for wave speed, period, interference, refraction and Doppler shift. The central relationship is $v=f\lambda=\lambda/T$, but knowing it does not replace understanding what each variable represents. The data booklet also provides constructive and destructive path-difference conditions and the double-source fringe-spacing relationship. Additional equations apply to diffraction gratings, simple harmonic motion and Doppler situations, depending on the syllabus level and context. Practise locating equations in the current booklet, then explain the physical conditions that make each equation valid.

How can I distinguish a displacement-position graph from a displacement-time graph?

Read the horizontal-axis label before interpreting any feature of the graph. A displacement-position graph shows different particles at one instant, so the horizontal spacing between consecutive in-phase points gives the wavelength. A displacement-time graph shows the motion of one point, so the corresponding spacing gives the period. Both graphs may look sinusoidal, which is why relying only on their shape is dangerous. Once you identify the axis, use $f=1/T$ or $v=f\lambda$ as appropriate.

What are the most common standing-wave mistakes in IB Physics?

Students often confuse the distance between adjacent nodes with a full wavelength, although it is $\lambda/2$. They may also place an antinode at a fixed string end or a closed pipe end, where a displacement node is required. Another error is assuming that all pipes support the same sequence of harmonics. Sketching the boundary conditions before calculating usually prevents these mistakes. Remember that standing waves transfer no net energy along the system, even though individual particles oscillate.

How should I choose the signs in a Doppler-effect equation?

First predict whether the observed frequency must be higher or lower than the emitted frequency. Approaching motion should produce a higher observed frequency, while separating motion should produce a lower one. Next identify whether the source moves, the observer moves, or both, because their speeds enter different parts of the sound-wave relationship. Choose signs that make the equation agree with your physical prediction rather than memorizing an isolated sign pattern. After calculating, compare the observed frequency with the source frequency to check that the direction is sensible.

Are waves questions different at IB Physics SL and HL?

SL and HL students share substantial Theme C content, including the wave model, interference, standing waves, resonance and qualitative wave behaviour. HL includes additional depth and mathematical treatment in specified parts of the syllabus, including selected simple harmonic motion, wave phenomena and Doppler-effect content. This can lead to more demanding derivations, diffraction calculations or multi-step applications for HL students. However, SL questions can still require careful data analysis and explanations rather than simple formula substitution. Always practise from resources labelled for your current syllabus and level.

Are video solutions better than rereading waves notes?

Video solutions are usually more effective for learning exam method, provided you attempt the question before watching. The initial attempt exposes whether your difficulty comes from the concept, diagram, equation choice, algebra or wording. A worked solution then shows the sequence of decisions that a finished written answer may hide. Pause the video at each step, predict what should happen next, and redo the question without assistance afterwards. Notes remain useful for repairing a specific knowledge gap, but they should support question practice rather than replace it.

IB Physics Waves Questions: A Practical Exam Guide

RevisionDojo Team

•7/31/2026•11 min read

This site uses cookie tracking technologies. Learn more in our Cookie Policy.

IB Physics Waves Questions: A Practical Exam Guide

RevisionDojo Team

•7/31/2026•11 min read

IB Physics waves questions become much easier once you recognize their recurring structures. Most ask you to interpret a graph, select a wave relationship, apply boundary or interference conditions, and explain the result using precise physics. The most efficient preparation is to attempt questions independently and then watch each method worked through step by step, rather than repeatedly rereading notes.

In the current course, waves appear under Theme C: Wave behaviour, which includes simple harmonic motion, the wave model, wave phenomena, standing waves and resonance, and the Doppler effect. The official IB Physics page provides the current subject brief, while the IB Physics specimen papers show how these ideas can be assessed.

How waves are examined in IB Physics

The current assessment model has Paper 1A, containing multiple-choice questions, Paper 1B, focused on data analysis, and Paper 2, containing short-response and extended-response work. The IB describes Paper 1A and 1B as parts of the first external examination, followed by Paper 2 as the second.

Waves can therefore appear in several forms:

Question format	What you may need to do	Main risk
Multiple choice	Interpret a graph, compare frequencies or select an equation	Choosing a plausible answer without checking units
Data analysis	Find gradients, identify trends or use uncertainties	Treating graph coordinates as physical quantities without reading the axes
Short response	Calculate wavelength, fringe spacing or observed frequency	Substituting before identifying the correct model
Explanation	Describe diffraction, resonance or phase relationships	Giving a description without explaining the physics
Extended response	Combine waves with energy, mechanics or experimental data	Losing the logical link between steps

The IB Physics curriculum update confirms that graphing, units and uncertainties may be assessed through Paper 1B. Waves are particularly suitable for this because questions can supply displacement, intensity, frequency-response or spectral data.

The core method for answering waves questions

Use the same sequence whenever you meet an unfamiliar problem.

Identify the wave system. Decide whether the question concerns a travelling wave, standing wave, interference, refraction, diffraction, resonance or Doppler shift.
Read the representation carefully. Determine whether a graph shows displacement against position, displacement against time, intensity against position, or another relationship.
Mark known quantities with units. Convert centimetres, nanometres and kilohertz into SI units before substitution.
Choose a physical principle. Start from relationships such as $v=f\lambda$ , a path-difference condition or a boundary condition.
Substitute symbolically where possible. This makes the reasoning visible and reduces calculator mistakes.
Check direction and scale. Ask whether the calculated frequency, angle or wavelength should increase or decrease.
State the result with a unit and suitable significant figures.

Keep the current IB Physics data booklet beside you during practice. Knowing that an equation exists is not enough; you must recognize when its assumptions match the question.

Recurring IB Physics waves question types

Reading wave graphs

A displacement-position graph is a snapshot of the entire wave at one instant. The horizontal distance between consecutive points in phase, such as two crests, is the wavelength. A displacement-time graph follows one location, so the horizontal separation between successive crests is the period.

Suppose a displacement-position graph has crests at $x=0.20\text{ m}$ and $x=0.80\text{ m}$ , while the frequency is $5.0\text{ Hz}$ . Then

\lambda=0.80-0.20=0.60\text{ m}

v=f\lambda=(5.0)(0.60)=3.0\text{ m s}^{-1}.

A common trap is to interpret the crest-to-trough distance as one wavelength. It is only half a wavelength.

Interference, diffraction and refraction

Interference questions often require a path-difference condition. Constructive interference occurs when the path difference is $n\lambda$ , while destructive interference occurs when it is $(n+\tfrac12)\lambda$ , where $n$ is an integer.

For a double-source pattern with small angular separation, the data booklet gives

s=\frac{\lambda D}{d},

where $s$ is fringe spacing, $D$ is source-to-screen distance and $d$ is source separation. If $\lambda=600\text{ nm}$ , $D=2.0\text{ m}$ and , converting both prefixes first gives , or .

For diffraction, avoid saying only that a wave “bends.” State that it spreads after passing through an aperture or around an obstacle, with more noticeable spreading when the aperture size is comparable to the wavelength. In refraction questions, frequency remains unchanged at the boundary, while speed and wavelength may change.

Standing waves and resonance

A standing wave forms through the superposition of two identical waves travelling in opposite directions. Nodes have zero amplitude, while antinodes have maximum amplitude. Adjacent nodes or adjacent antinodes are separated by $\lambda/2$ , but a node and its neighbouring antinode are separated by $\lambda/4$ .

Boundary conditions matter. A string fixed at an end has a displacement node there; an open pipe has a displacement antinode at its open end, while a closed end has a displacement node. Sketch the permitted pattern before using a harmonic relationship, especially for pipes closed at one end.

Resonance occurs when a driving frequency matches, or is sufficiently close to, a natural frequency and energy transfer produces a large response. Damping reduces the response and broadens the resonance curve, so an explanation should connect the graph’s shape to energy loss rather than merely state that amplitude decreases.

Doppler-effect questions

Begin with direction, not signs. If source and observer approach one another, wavefronts arrive more frequently and the observed frequency is higher. If they separate, the observed frequency is lower.

For sound, distinguish between a moving source and a moving observer before selecting the relevant data-booklet equation. For light at speeds much smaller than $c$ , connect fractional frequency or wavelength change to relative speed and identify whether the spectral lines show a redshift or blueshift. A correct calculation with the wrong physical direction usually reveals a sign-choice error.

How to write explanations that earn marks

IB command terms determine the required depth. State requires a concise answer, describe asks what happens, and explain requires a physical cause linked to the observation. For example:

Weak: “The sound becomes louder at resonance.”
Stronger: “At resonance, the driving frequency matches the system’s natural frequency, so energy is transferred efficiently and the oscillation amplitude increases.”

Use vocabulary such as coherent, path difference, phase difference, superposition, natural frequency and boundary condition accurately. Do not replace an explanation with an equation unless the question specifically asks for a calculation.

Common mistakes and how to prevent them

Confusing particle motion with wave propagation. In a transverse wave, particles oscillate perpendicular to the direction of energy transfer.
Reading amplitude as the vertical distance from crest to trough. Amplitude is measured from equilibrium to a crest or trough.
Assuming frequency changes during refraction. The source fixes the frequency.
Using degrees and radians interchangeably in phase questions.
Ignoring intensity when interpreting interference diagrams. Intensity is related to amplitude squared, not directly to amplitude.
Applying an open-pipe pattern to a pipe closed at one end.
Selecting Doppler signs mechanically instead of predicting whether frequency should rise or fall.
Giving excessive significant figures or omitting units.

The fastest effective practice routine

For exam technique, worked video solutions are more useful than another passive reading of the chapter. Attempting a question first forces you to make decisions; watching the solution immediately afterwards reveals the exact point where your model, diagram or algebra failed.

Use this cycle:

Choose one subtopic from the Theme C Wave Behaviour Questionbank.
Attempt three to five questions without looking at the solution.
Watch the corresponding per-question Physics video solutions, pausing before each major step to predict what comes next.
Record the cause of each error, such as graph reading, equation choice, boundary condition, unit conversion or explanation wording.
Repeat a similar question one or two days later without assistance.

If a conceptual gap appears, use the Wave Behaviour topic resources or focused Wave Phenomena practice. Jojo AI can help identify why an answer lost credit, but you should still reconstruct the solution independently.

Conclusion

Success with IB Physics waves questions depends on recognizing the wave model, reading diagrams precisely and connecting equations to physical conditions. The recurring traps involve graph axes, phase, boundary conditions, interference paths, refraction frequency and Doppler direction.

RevisionDojo’s Physics Questionbank and per-question video solutions support the most productive sequence: attempt, inspect the worked method, diagnose the error and retry. Use IB Physics revision notes only to repair specific conceptual gaps, then return to timed waves questions as quickly as possible.
